22×57 plan — ten rooms with attached toilets, two floors — image 1 of 21 / 2
2D Floor Plans

22×57 plan — ten rooms with attached toilets, two floors

22x57 ft · G+1

Design code DS1073 — quote it when you call or message us.

Design fee

₹5,499

From our rate card

  • ₹5,499 · 2D floor plan · Ground + first floor · for a plot of 1,254 sq ft
Ask on WhatsAppDownload PDF brochure
Design type
2D Floor Plans
Design code
DS1073
Plot size
22 × 57 ft
Plot area
1,254 sq ft (139 gaj)
Floors
Two floors (G+1)
Vastu
Adjusted for Vastu on request

About this design

Ground and first floor plans for a narrow 22×57 ft plot: five rooms with attached toilets on each floor (one of 15'-9" × 9'-0", four of 11'-4" × 9'-0" on the ground floor), a 4 ft side passage, a hall of 18'-0" × 9'-0" and the staircase at the front.

  • Ten rooms
  • Attached toilets
  • Side passage
  • Hall at the front

What you get

  • 2D plan of every floor, drawn in AutoCAD
  • Room sizes and overall dimensions
  • Furniture layout
  • Doors, windows and staircase marked
  • Adapted to your plot size and facing

Free consultation · Reply within one working day

Questions about this design

Can I customise 22×57 plan — ten rooms with attached toilets, two floors?

Yes. Tap “Customize This Design” and we will adapt room sizes, floors, facing and the elevation to your plot and budget.

Is 22×57 plan — ten rooms with attached toilets, two floors Vastu compliant?

Tell us you want Vastu and we re-plan the entrance, kitchen, bedrooms and puja room to follow it when we adapt the design to your plot.

Will this design fit my 22x57 plot?

It is drawn for a 22x57 ft plot. Share your exact plot dimensions and setbacks and we will confirm the fit before you pay.

What happens after I send a request?

A designer calls you within one working day to understand your needs, then shares a quote and timeline.
