2D Floor PlansVastu20x27 ft · 5 BHK · G+2 · North facing
Manoj Bhagat - Bareilly - 20'X27' (G+2)
1,860 sq ft built-up · Code DS1206
Cities we serve
Design SQR draws house plans (naksha), 3D elevations and structural, electrical and plumbing drawings for plots in Bareilly: prepared for BDA approval, designed for Bareilly's composite climate and the structure checked for Seismic Zone III.
Build in Bareilly
Built-up area, design included.
Call +91 8920757366₹ per sq ft of built-up area, design included.
Build Basic
₹1,799 / sq ft
Quality essentials, fixed price
Build Standard
₹2,099 / sq ft
Our most chosen package
Build Premium
₹2,599 / sq ft
Luxury finishes, turnkey
Sources: Bareilly Development Authority · UP Building Bye-laws 2025 (GDA) · LDA: building plan approval system (FASTPAS) · RealEstateIndia: residential plots in Bareilly · BMTPC: Vulnerability Atlas, Bareilly district · CGWB: Bareilly district groundwater brochure · IS 1893 (Part 1):2016, Annex E · BEE Eco-Niwas Samhita 2024: climate zone map
Design SQR Bareilly के प्लॉट के लिए घर का नक्शा (2D और 3D), 3D एलिवेशन और स्ट्रक्चरल, इलेक्ट्रिकल व प्लंबिंग ड्रॉइंग बनाता है, जो BDA से नक्शा पास कराने के लिए तैयार होते हैं। हम वास्तु के हिसाब से भी घर का नक्शा बनाते हैं। मुफ़्त सलाह के लिए कॉल या WhatsApp करें।
WhatsApp पर प्लॉट का साइज़ भेजेंIndicative rates, as of October 2026: ₹1,799 per sq ft (Build Basic), ₹2,099 per sq ft (Build Standard), ₹2,599 per sq ft (Build Premium), design included. The final price is confirmed after a free site visit.
The Bareilly Development Authority (BDA), under the UP Building Bye-laws 2025. Plans go online on FASTPAS (map.up.gov.in), which replaced UPOBPAS in 2026. Under UP's 2025 building bye-laws, house plots up to 100 sq m need no permission, only online registration with a ₹1 token and a self-certified plan (not in mela areas, unauthorised colonies or on government or disputed land), and single-house plots up to 500 sq m in approved layouts get instant online approval once a licensed professional certifies the plan. We prepare the drawings it asks for and guide you through the approval.
The authority works in square metres, while plots are bought and sold in sq ft and gaj (square yards). Bareilly listings show plots of about 100–200 gaj on Pilibhit Road and Badaun Road and in Rithora and Bithri Chainpur, and some of 900–1,400 sq ft. We draw plans for any plot size, including odd shapes.
Seismic Zone III. IS 1893's table of towns lists Bareilly in Zone III, though BMTPC's Vulnerability Atlas (2019) puts 51.1% of Bareilly district in Zone IV, so a plot outside the city may be in Zone IV. BIS withdrew its 2025 seismic map in March 2026, so the IS 1893:2016 zones still apply. We design the structure to IS 1893 for this zone: column sizes, steel and foundations are calculated, not guessed.
Bareilly lies in the Ramganga basin on deep Gangetic alluvium: sandy khadar soil along the rivers and sandy, loamy or clayey bangar soil on the uplands (CGWB). BMTPC marks 31.1% of the district as flood-prone, so check the plot's level against nearby rivers and drains. We size the foundation after a soil check.
Yes. "ghar ka naksha" is how many people in Bareilly write "house plan" in Hindi. We draw the complete set: floor plans, 3D elevation, and structural, electrical and plumbing drawings.
Yes. We place the kitchen, master bedroom, puja room, toilets and entrance as vastu suggests wherever your Bareilly plot allows, and tell you plainly where it cannot. It is all done online, so you can share the plot details on WhatsApp.
Send your plot size on WhatsApp — a designer calls back within one working day.
